Dan Strong Polypropylene - 12 Strand



Teklif İsteyin

Dia. mm Dia. Inch Cir. inch Wt.Per 220 Mtrs. in Kgs. Wt Per 200 Mtrs. in Kgs. Wt.Per 220 Mtrs. in Lbs. Wt.Per 200 Mtrs. in Lbs. Mtr/kg Feet/kg MBL / kgf MBL / Lbs MBL / KN Maximum Length Mtr.
52 2-1/16 6-1/2 274 249.09 602.80 548 0.80 2.63 47400 104280 464.71 900
56 2-1/4 7 316 287.27 695.20 632 0.70 2.28 55100 121220 540.20 800
60 2-3/8 7-1/2 364 330.91 800.80 728 0.60 1.98 61700 135740 604.90 700
64 2-1/2 8 413 375.45 908.60 826 0.53 1.75 70500 155100 691.18 600
68 2-15/16 8-1/2 470 427.27 1034 940 0.47 1.54 79800 175560 782.35 550
72 2-7/8 9 523 475.45 1150.60 1046 0.42 1.38 89200 196240 874.51 500
76 3 9-1/2 586 532.73 1289.20 1172 0.38 1.23 98500 216700 965.69 450
80 3-5/32 10 648 589.09 1425.60 1296 0.34 1.11 108400 238480 1062.75 400
84 3-1/2 10-1/2 716 650.91 1575.20 1432 0.31 1.01 117800 259160 1154.90 350
88 3-7/16 11 787 715.45 1731.40 1574 0.28 0.92 127700 280940 1251.96 320
96 3-13/16 12 934 849.09 2054.80 1868 0.24 0.77 150800 331760 1478.43 270
104 4-1/2 13 1095 995.45 2409 2190 0.20 0.66 171700 377740 1683.33 220
108 4-15/16 13-1/2 1166 1060 2565.2 2332 0.19 0.62 186000 409200 1823.52 220
112 1-7/8 14 - 1124.5 - 2474 0.17 0.56 200200 440440 1962.74 200
120 5 15 - 1200 - 2640 0.15 0.49 231600 509520 2270.58 180
