Dan Strong Polypropylene - 8 Strand



Teklif İsteyin

Dia. mm Dia. Inch Cir. inch Wt.Per 220 Mtrs. in Kgs. Wt Per 200 Mtrs. in Kgs. Wt.Per 220 Mtrs. in Lbs. Wt.Per 200 Mtrs. in Lbs. Mtr/kg Feet/kg MBL / kgf MBL / Lbs MBL / KN Maximum Length Mtr.
40 1-5/8 5 158 143.64 347.60 316 1.39 4.57 28000 61600 274.51 270
44 1-3/4 5-1/2 193.60 176 425.92 387.20 1.14 3.73 33750 74250 330.88 220
48 1-15/16 6 229 208.18 503.80 458 0.96 3.15 39500 86900 387.25 520
52 2-1/16 6-1/2 270.40 245.82 594.88 540.80 0.81 2.67 45750 100650 448.53 450
56 2-1/4 7 312 283.64 686.40 624 0.71 2.31 52000 114400 509.80 380
60 2-3/8 7-1/2 359 326.36 789.80 718 0.61 2.01 59500 130900 583.33 330
64 2-1/2 8 407 370 895.40 814 0.54 1.77 67550 148610 662.25 290
68 2-15/16 8-1/2 460 418.18 1012 920 0.48 1.57 76000 167200 745.10 260
72 2-7/8 9 515 468.18 1133 1030 0.43 1.40 84500 185900 828.43 450
76 3 9-1/2 574 521.82 1262.80 1148 0.38 1.26 94000 206800 921.57 400
80 3-1/4 10 638 580 1403.60 1276 0.34 1.13 104000 228800 1019.61 350
84 3-1/2 10-1/2 703 639.09 1546.60 1406 0.31 1.03 114000 250800 1117.65 320
88 3-15/16 11 772 701.82 1698.40 1544 0.28 0.93 125000 275000 1225.49 300
92 3-7/8 11-1/2 846 769.09 1861.20 1692 0.26 0.85 136000 299200 1333.33 270
96 3-3/4 12 916 832.73 2015.20 1832 0.24 0.79 148000 325600 1450.98 250
100 4 12-1/2 1000 909.09 2200 2000 0.22 0.72 159166 350165.2 1560.45 220
104 4-1/2 13 1078 980 2371 2155.45 0.20 0.67 169500 372900 1661.76 220
112 1-7/8 14 - 1026.40 - 2258 0.17 0.55 195600 430320 1917.65 180
116 4-3/4 14-1/2 - 1008.60 - 2218 0.16 0.52 207030 455466 2029.71 170
120 5 15 - 1047 - 2303 0.15 0.49 224600 494120 2201.96 160
