| Rope Ø / mm |
unit mass / kg/100m |
min aggregate breaking force [kN] tensile grade / 1570 N/mm2 |
min aggregate breaking force [kN] tensile grade / 1770 N/mm2 |
min aggregate breaking force [kN] tensile grade / 1860 N/mm2 |
min aggregate breaking force [kN] tensile grade / 1960 N/mm2* |
| 22 | 238 | 433 | 488 | 513 | 543 |
| 24 | 284 | 516 | 582 | 612 | 646 |
| 26 | 334 | 608 | 685 | 720 | 759 |
| 28 | 387 | 704 | 793 | 833 | 880 |
| 30 | 445 | 809 | 912 | 958 | 1010 |
| 32 | 505 | 919 | 1036 | 1089 | 1149 |
| 34 | 600 | 1077 | 1214 | 1275 | 1343 |
| 36 | 673 | 1207 | 1361 | 1430 | 1505 |
| 38 | 749 | 1345 | 1516 | 1593 | 1677 |
| 40 | 830 | 1490 | 1680 | 1765 | 1858 |
| 43 | 916 | 1643 | 1852 | 1946 | 2049 |
| 44 | 1005 | 1803 | 2033 | 2136 | 2249 |
| 46 | 1098 | 1971 | 2222 | 2335 | 2458 |
| 48 | 1196 | 2146 | 2419 | 2542 | 2676 |
| 50 | 1298 | 2328 | 2625 | 2758 | 2904 |
| 52 | 1403 | 2518 | 2839 | 2983 | 3141 |
| 54 | 1514 | 2716 | 3061 | 3217 | 3387 |
| 56 | 1628 | 2920 | 3292 | 3460 | 3642 |
| 58 | 1746 | 3133 | 3532 | 3711 | 3907 |
| 60 | 1869 | 3353 | 3780 | 3972 | 4181 |
| 62 | 1995 | 3580 | 4036 | 4241 | 4485 |
| 64 | 2126 | 3814 | 4300 | 4519 | 4757 |
| 66 | 2261 | 4057 | 4573 | 4806 | 5059 |
