| Nominal rope Ø / mm |
Weight approx / kg/100 m |
Minimum breaking force Fmin 1770 / kN |
Minimum breaking force Fmin 1960 / kN |
| 4 | 7 | 11,7 | 13 |
| 5 | 11 | 18,3 | 20,2 |
| 6 | 16 | 26,3 | 29,2 |
| 7 | 22 | 35,8 | 39,7 |
| 8 | 27 | 43,7 | 48,6 |
| 9 | 35 | 56,9 | 63,3 |
| 10 | 42 | 68,2 | 76 |
| 11 | 54 | 86,3 | 96,1 |
| 12 | 65 | 106 | 118 |
| 13 | 76 | 122 | 136 |
| 14 | 85 | 137 | 152 |
| 15 | 103 | 166 | 184 |
| 16 | 116 | 187 | 208 |
| 17 | 130 | 210 | 233 |
| 18 | 146 | 236 | 262 |
| 19 | 161 | 260 | 289 |
| 20 | 178 | 288 | 320 |
| 21 | 195 | 315 | 351 |
| 22 | 223 | 361 | 401 |
| 23 | 241 | 390 | 434 |
| 24 | 261 | 422 | 469 |
| 25 | 285 | 462 | 513 |
| 26 | 307 | 497 | 552 |
| 27 | 326 | 528 | 587 |
| 28 | 358 | 580 | 645 |
| 29 | 382 | 620 | 689 |
| 30 | 409 | 663 | 736 |
| 31 | 434 | 703 | 781 |
| 32 | 459 | 745 | 827 |
| 33 | 497 | 806 | 896 |
| 34 | 528 | 855 | 951 |
| 35 | 545 | 884 | 982 |
| 36 | 588 | 953 | 1058 |
| 37 | 618 | 1002 | 1113 |
| 38 | 660 | 1069 | 1188 |
| 39 | 691 | 1120 | 1244 |
| 40 | 728 | 1180 | 1311 |
| 41 | 760 | 1232 | 1369 |
| 42 | 806 | 1307 | 1452 |
| 43 | 844 | 1368 | 1520 |
| 44 | 885 | 1434 | 1594 |
| 45 | 911 | 1481 | 1640 |
| 46 | 956 | 1550 | 1723 |
| 47 | 994 | 1616 | 1789 |
| 48 | 1035 | 1678 | 1864 |
| 49 | 1080 | 1756 | 1944 |
| 50 | 1125 | 1824 | 2027 |
| 51 | 1170 | 1902 | 2107 |
| 52 | 1203 | 1951 | 2168 |
| 53 | 1264 | 2054 | 2275 |
| 54 | 1315 | 2133 | 2369 |
| 55 | 1361 | 2212 | 2450 |
| 56 | 1432 | 2323 | 2581 |
| 57 | 1462 | 2376 | 2631 |
| 58 | 1531 | 2482 | 2758 |
| 59 | 1566 | 2546 | 2819 |
| 60 | 1640 | 2659 | 2954 |
| 61 | 1674 | 2722 | 3013 |
| 62 | 1729 | 2811 | 3113 |
| 63 | 1786 | 2903 | 3214 |
| 64 | 1843 | 2996 | 3317 |
| 65 | 1901 | 3090 | 3421 |
| 66 | 1960 | 3186 | 3528 |
| 67 | 2019 | 3283 | 3635 |
| 68 | 2080 | 3382 | 3745 |
| 69 | 2142 | 3482 | 3856 |
| 70 | 2204 | 3584 | 3968 |
| 71 | 2268 | 3687 | 4082 |
| 72 | 2332 | 3792 | 4198 |
| 73 | 2397 | 3897 | 4315 |
| 74 | 2463 | 4005 | 4435 |
| 75 | 2531 | 4114 | 4555 |
