| Dia. / mm |
Dia./ inch |
Cir / inch |
Wt. Per 220 Mtrs. in Kgs. |
Wt. Per 200 Mtrs. in Kgs. |
Wt. Per Wt. Per 220 Mtrs. in Lbs |
Wt. Per 200 Mtrs. in Lbs |
Mtr/ Kg |
Feet/ Kg |
MBL / kgf |
MBL / LBs |
MBL / KN |
Maximum Length Mtr. |
| 517 | 40 | 1-5/85 | 5 | 192.50 | 175 | 423.50 | 385 | 1.14 | 3.75 | 34200 | 75240 | 335 |
| 517 | 44 | 1-3/4 | 5-1/2 | 228.80 | 208 | 503.36 | 457 | 0.96 | 3.15 | 40800 | 89760 | 400 |
| 517 | 48 | 1-15/16 | 6 | 264 | 240 | 580.80 | 528 | 0.83 | 2.73 | 47400 | 104280 | 465 |
| 517 | 52 | 2-1/16 | 6.5 | 310.20 | 282 | 682.44 | 620.40 | 0.71 | 2.33 | 55500 | 122100 | 544 |
| 517 | 56 | 2-1/4 | 7 | 345.40 | 314 | 759.88 | 690.80 | 0.64 | 2.09 | 63200 | 139040 | 620 |
| 517 | 60 | 2-3/8 | 7.5 | 402.60 | 366 | 885.72 | 805.20 | 0.55 | 1.79 | 72400 | 159280 | 710 |
| 517 | 64 | 2-1/2 | 8 | 453.20 | 412 | 997.04 | 906.40 | 0.49 | 1.59 | 81600 | 179520 | 800 |
| 517 | 68 | 2-15/16 | 8.5 | 510.40 | 464 | 1122.88 | 1020.80 | 0.43 | 1.41 | 91800 | 201960 | 900 |
| 517 | 72 | 2-7/8 | 9 | 567.60 | 516 | 1248.72 | 1135.20 | 0.39 | 1.27 | 102000 | 224400 | 1000 |
| 517 | 76 | 3 | 9.5 | 622.60 | 566 | 1369.72 | 1245.20 | 0.35 | 1.16 | 112000 | 246400 | 1098 |
| 517 | 80 | 3-1/4 | 10 | 701.80 | 638 | 1543.96 | 1403.60 | 0.31 | 1.03 | 125000 | 275000 | 1225 |
| 517 | 88 | 3-15/16 | 11 | 836 | 760 | 1839.20 | 1672 | 0.26 | 0.86 | 148000 | 325600 | 1451 |
| 517 | 96 | 3-3/4 | 12 | 983.40 | 894 | 2163.48 | 1966.80 | 0.22 | 0.73 | 174000 | 382800 | 1706 |
| 517 | 104 | 4-1/2 | 13 | 1155 | 1050 | 2541 | 2310 | 0.19 | 0.62 | 198300 | 436260 | 1944 |
| 517 | 112 | 1-7/8 | 14 | - | 1254 | - | 2758.80 | 0.18 | 0.58 | 230800 | 507760 | 2263 |
| 517 | 120 | 5 | 15 | - | 1120 | - | 2464 | 0.20 | 0.64 | 263000 | 578600 | 2578.43 |
