| rope Ø / mm |
unit mass / kg-100m |
min aggregate breaking force [kN] tensile grade / 1570 N/nm2 |
min aggregate breaking force [kN] tensile grade / 1770 N/nm2 |
min aggregate breaking force [kN] tensile grade / 1960 N/nm2 |
| 28 | 309 | 517 | 582 | 645 |
| 30 | 355 | 593 | 669 | 741 |
| 32 | 403 | 675 | 761 | 843 |
| 34 | 455 | 762 | 859 | 952 |
| 36 | 511 | 855 | 963 | 1087 |
| 38 | 569 | 952 | 1073 | 1189 |
| 40 | 630 | 1055 | 1189 | 1317 |
| 42 | 695 | 1163 | 1311 | 1452 |
| 44 | 763 | 1277 | 1439 | 1594 |
| 46 | 834 | 1395 | 1573 | 1742 |
| 48 | 908 | 1519 | 1713 | 1897 |
| 50 | 985 | 1646 | 1859 | 2058 |
| 52 | 1055 | 1783 | 2010 | 2226 |
| 54 | 1149 | 1923 | 2168 | 2400 |
| 56 | 1236 | 2068 | 2331 | 2582 |
| 58 | 1325 | 2218 | 2501 | 2769 |
| 60 | 1418 | 2374 | 2676 | 2964 |
| 62 | 1515 | 2535 | 2858 | 3164 |
| 64 | 1614 | 2701 | 3045 | 3372 |
| 66 | 1716 | 2872 | 3238 | 2586 |
| 68 | 1822 | 3049 | 3437 | 3806 |
| 70 | 1930 | 3231 | 3643 | 4033 |
