Nominal rope Ø / mm |
Weight approx / kg/100 m |
Minimum breaking force Fmin 1770 / kN |
Minimum breaking force Fmin 1960 / kN |
Minimum breaking force Fmin 2160 / kN |
4 | 8 | 12,8 | 14,1 | 15,4 |
5 | 12 | 19,9 | 22,1 | 24 |
6 | 17 | 28,7 | 31,8 | 34,6 |
7 | 23 | 39,1 | 43,3 | 47,1 |
8 | 30 | 51 | 56,5 | 61,6 |
9 | 38 | 64,6 | 71,5 | 77,9 |
10 | 47 | 79,8 | 88,4 | 96,6 |
11 | 57 | 96,9 | 107 | 117 |
12 | 68 | 115 | 128 | 139 |
13 | 80 | 135 | 150 | 163 |
14 | 92 | 156 | 173 | 188 |
15 | 106 | 179 | 199 | 217 |
16 | 121 | 204 | 226 | 246 |
17 | 136 | 230 | 255 | 278 |
18 | 153 | 258 | 286 | 312 |
19 | 170 | 288 | 319 | 347 |
20 | 189 | 319 | 354 | 385 |
21 | 208 | 352 | 389 | 424 |
22 | 228 | 386 | 428 | 465 |
23 | 250 | 422 | 468 | 509 |
24 | 272 | 459 | 509 | 554 |
25 | 295 | 498 | 552 | 601 |
26 | 319 | 539 | 597 | 650 |
27 | 344 | 581 | 643 | 701 |
28 | 370 | 626 | 693 | 754 |
29 | 397 | 671 | 743 | 809 |
30 | 425 | 718 | 795 | 866 |
31 | 457 | 772 | 855 | 932 |
32 | 487 | 823 | 911 | 992 |
33 | 518 | 875 | 969 | 1055 |
34 | 549 | 929 | 1030 | 1121 |
35 | 582 | 984 | 1090 | 1187 |
36 | 616 | 1041 | 1153 | 1256 |
37 | 651 | 1100 | 1221 | 1328 |
38 | 686 | 1168 | 1298 | 1413 |
39 | 723 | 1222 | 1353 | 1474 |
40 | 761 | 1285 | 1424 | 1551 |
41 | 799 | 1351 | 1496 | 1629 |
42 | 838 | 1418 | 1574 | 1713 |
43 | 879 | 1486 | 1645 | 1792 |
44 | 920 | 1556 | 1723 | 1876 |
45 | 955 | 1615 | 1788 | 1948 |
46 | 1006 | 1700 | 1883 | 2050 |
47 | 1042 | 1762 | 1951 | 2125 |
48 | 1095 | 1851 | 2050 | 2233 |
49 | 1133 | 1915 | 2121 | 2309 |
50 | 1188 | 2009 | 2224 | 2423 |
51 | 1227 | 2075 | 2298 | 2502 |
52 | 1285 | 2173 | 2406 | 2620 |
53 | 1325 | 2241 | 2481 | 2702 |
54 | 1386 | 2343 | 2594 | 2826 |
55 | 1427 | 2413 | 2672 | 2910 |
56 | 1491 | 2519 | 2791 | 3039 |
57 | 1533 | 2592 | 2870 | 3125 |
58 | 1599 | 2703 | 2993 | 3260 |
59 | 1642 | 2776 | 3074 | 3348 |
60 | 1711 | 2893 | 3203 | 3489 |
61 | 1756 | 2968 | 3286 | 3579 |
62 | 1827 | 3089 | 3420 | 3725 |
63 | 1873 | 3165 | 3505 | 3818 |
64 | 1947 | 3291 | 3645 | 3969 |
65 | 1993 | 3370 | 3732 | 4064 |
66 | 2071 | 3500 | 3876 | 4221 |
67 | 2118 | 3580 | 3964 | 4318 |
68 | 2198 | 3715 | 4114 | 4481 |
69 | 2246 | 3798 | 4205 | 4380 |
70 | 2329 | 3937 | 4360 | 4749 |
71 | 2378 | 4021 | 4452 | 4849 |
72 | 2446 | 4134 | 4579 | 4986 |
73 | 2514 | 4251 | 4706 | 5126 |
74 | 2584 | 4367 | 4837 | 5268 |
75 | 2654 | 4486 | 4968 | 5410 |
76 | 2725 | 4607 | 5102 | - |
77 | 2797 | 4729 | 5237 | - |
78 | 2871 | 4853 | 5374 | - |
79 | 2945 | 4978 | 5512 | - |
80 | 3020 | 5104 | 5653 | - |
81 | 3096 | 5233 | 5794 | - |
82 | 3173 | 5364 | 5939 | - |
83 | 3250 | 5494 | 6084 | - |
84 | 3329 | 5628 | 6232 | - |
85 | 3409 | 5763 | 6381 | - |
86 | 3490 | 5899 | 6532 | - |
87 | 3571 | 6037 | 6685 | - |
88 | 3654 | 6177 | 6840 | - |
89 | 3737 | 6318 | 6996 | - |
90 | 3822 | 6461 | 7154 | - |
91 | 3907 | 6605 | 7314 | - |
92 | 3994 | 6751 | 7476 | - |
93 | 4081 | 6899 | 7639 | - |
94 | 4169 | 7047 | 7804 | - |
95 | 4258 | 7199 | 7971 | - |
96 | 4348 | 7351 | 8140 | - |
97 | 4439 | 7505 | 8310 | - |
98 | 4531 | 7660 | 8482 | - |
99 | 4624 | 7817 | 8656 | - |
100 | 4718 | 7976 | 8832 | |
